Sunny Medical Equipment Limited

Model

SY-G076-2

Pumping Mechanism

Curvilinear peristaltic

IV Set

Compatible with IV sets of any standard

Flow Rate

0.1-1500 ml/h (in 0.1 ml/h increments)

Purge, Bolus

100-1500 ml/h (in 1 ml/h increments)

Purge when pump stops, bolus when pump starts

Bolus volume

1-20 ml (in 1 ml increments)

Accuracy

±3%

VTBI

1-9999 ml

Infusion Mode

ml/h, drop/min, time-based

KVO Rate

0.1-5 ml/h (in 0.1 ml/h increments)

Alarms

Occlusion, air-in-line, door open, end program, low battery, end battery,

AC power off, motor malfunction, system malfunction, reminder alarm

Additional Features

Real-time infused volume / bolus rate / bolus volume / KVO rate,

automatic power switching, mute key, purge, bolus, system memory,

key locker, change flow rate without stopping the pump

Occlusion Sensitivity

High, medium, low

Air-in-line Detection

Ultrasonic detector

Wireless management

Optional

Power Supply, AC

110/230 V (optional), 50-60 Hz, 20 VA

Battery

9.6±1.6 V, rechargeable

Battery Life

5 hours at 30 ml/h

Working Temperature

10-40℃

Relative Humidity

30-75%

Atmospheric Pressure

700-1060 hpa

Size

174*126*215 mm

Weight

2.5 kg

Safety Classification

Class Ⅰ, type CF
